Tendon injuries are among the most prevalent musculoskeletal conditions.1 Surgical repair of the ruptured tendon is essential, however, the repair is inefficient. The limitation factors of the successful resolution of tendon lesions include: tendon heals slowly in approximately 8-12 weeks, the structural and mechanical properties of the healed tendon are less satisfactory than the normal tendon, and there is high probability of the occurrence of the lesion.2,3 Tendon repair is a complicated process which starts, continues and ends by the means of various mediators.4,5
The growth factors are among the most significant mediators involved in healing that optimize the strength of healed tendons. At the beginning of tendon healing process, growth factors are temporarily elevated in the injured site and initiate and stimulate the healing process and decrease in number with time.6,7 Reportedly, a delay of time-dependent decrease in blood derived products, can improve tendon healing.8 Exogenous growth factors therapy is regarded to be a means of enhancing cellular response to injury within the tendon, and ultimately the quality of the repair.9 Blood platelet released cocktail of growth factors such as the platelet-derived growth factor, transforming growth factor, fibroblastic growth factor, vascular endothelial growth factor, insulin-like growth factor, and epidermal growth factor when activated. RPR is an autologous concentration of platelets in a small volume of plasma.10,11 Clinically, there is a great demand to improve and accelerate the early time-period during tendon healing, as the re-rupture of repaired tendons occurs during the early healing stages. Therefore, we aimed to determine whether a local injection of PRP could improve the early stage healing of the tendon in rabbits DDF tendon cut model.
Materials and methods
Twenty adult male New Zealand White rabbits, weighing 2.2-2.5 kg were used in this study. Rabbits were adapted to handling in the period prior to surgery. The animals were kept in temperature of 22±3 °C, humidity (60 ± 5%) and a 12h light/dark cycle. The procedures were performed based on the guidelines of the Ethics Committee of the International Association for the Study of pain.12 The University Research Council approved all of the experiments. The animals were randomly divided into two equal groups with ten rabbits in each group.
PRP samples were prepared using a modification of the Curasan technique.13 The 6 ml autologous blood drawn from each rabbit was combined with 0.5 ml of anticoagulant citrate dextrose phosphate (ACD-A) to prevent coagulation. The blood was centrifuged at 1,200 rpm (160g) for 20 minutes to separate the plasma containing the platelets from the red cells. The plasma was drawn off the top, centrifuged for an additional 15 minutes at 2,000 rpm (400g) to separate the platelets. The platelet poor plasma was separated from the PRP along with the buffy coat. Platelet count was performed on each sample, including a peripheral blood count and PRP count.
All rabbits were anesthetized with 35 mg/kg, IM, Ketamine 5% (Alphasan, Woerden, Holand), 5 mg/kg, IM, Xylazine 2% (Alphasan, Woerden, Holand) and 1 mg/kg, IM, Acepromazine 2% (Hoogostraten, Belgium). A longitudinal skin incision was aseptically made exactly over the digital flexor (DDF) tendon. A complete horizontal incision cut was made through the midsubstance of the DDF tendon. This incision was instantly repaired with a locking-loop pattern. Immediately after the primary repair, 0.5 mL PRP and placebo was injected intratendinously, into the suture site in the treatment and control group, respectively. Skin closure was done in a routine manner. The limbs which underwent surgery were immobilized for two weeks. Three weeks after the operation all of the animals were sacrificed with thiopental sodium overdose (50 mg kg-1, IV, Sandoz, Austria) and tendon samples were harvested for histopathological (H&E and Masson's Trichrome staining) and biomechanical evaluations. For biomechanical studies, the DDF tendon samples from both limbs were harvested, wrapped in PBS soaked gauze and immediately stored at -20 ˚C.
Paraffin-embedded longitudinal sections were stained with hematoxylin and eosin (H&E) and Masson's Trichrome and were evaluated under a light microscope based on the following criteria: fibrillar linearity, fibrillar continuity, and angiogenesis in neotendon and epitenon, and epitenon thickness. The healed areas involving the longitudinally aligned collagen fibers were histologically evaluated. In this regard, the total area of neotendon between the severed ends of tendons was measured at 40× magnification and the area consisting the longitudinal pattern of collagen fibers was calculated. The ratio of the values was defined as the percentage of fibrillary linearity for each tendon. The width of the broadest part of neotendon involving the fibers in the direction of those in the original tendon was assessed at 40× magnification in both tendon-neotendon junctions and the ratio of their mean to the mean width of junctions was determined as the percentage of fibrillary continuity for each specimen. To investigate the number of angiogenesis within the neotendon and newly established epitenon, the quantity of blood capillaries was determined at 100× magnification. For this assessment, five randomly chosen files were examined per each tendon sample. The number of capillaries was averaged and reported for each specimen. The epitenon thickness was measured at 100× magnification in three randomly selected points of epitenon on both sides of neotendon and the records were averaged for each specimen.14
Ten tendons (five operated and five non-operated from the contralateral limb) from every one of the groups were submitted to the mechanical test of traction. The tendon from the non-operated legwas taken for comparison. Prior to mechanical testing, tendons were permitted to thaw while they were made wet in PBS immersed for 2 hours at room temperature. All tendons from the studied groups were submitted to the mechanical test of traction using the testing machine (Series Z010; Zwick GmbH & Co. KG, Ulm, Germany). In order to prevent tendon slippage during tensile testing, 360 grit sandpaper was attached to the end of each specimen for better clamping. The upper clamp was attached to a 500 N load cell and its displacement was controlled with a computer. The dynamic testing took place under axial tension with a constant speed of 50 mm/minute.15 The mechanical testing involved a single-cycle-to-failure. The power and elongation of the tendon were repeatedly measured until tendon lost its force. The manner of failure was optically perceived and recorded. For every tendon the force-elongation curve was formed and the following mechanical parameters were gained: force at failure (N), energy absorption capacity (N.mm) and stiffness (N.mm-1).The data were calculated as a percentage of values of healing tendon as non-operated contralateral in comparison with the limb to the same animal rather than using absolute testing values, in order to minimize the biological variation of tensile stress among individuals.16 The force at failure was determined as the utmost strength assessed in the tendon during the failure test. The values of energy absorption were evaluated by the measurement of the area under the force at maximum slope in the linear part of the force-elongation curve. Stiffness was established as the maximum slope in the linear part of the force-elongation curve.17
Statistical analysis was performed using Student's t-test, employing Graph Pad Prism, version 5.05 (Graph Pad software, San Diego, CA, USA). Experimental results were expressed as mean ± SD. The differences were regarded to be significant when p < 0.05.
Platelet counts confirmed that the preparation technique used in this study created a source of extremely concerted platelets with the collection efficiency of 35/13% (4.08). The average (standard deviation)
peripheral blood platelet count and average PRP platelet were 273811(43199)/mm3 and 1118006 (131695)/mm3, respectively (Fig. 1).
None of the rabbits died during the study period. There were no evidence of the presence of the clinical complications such as local infection and wound dehiscence. In addition, there was no adhesion formation between the tendons and their surrounding tissue in the PRP group. However, noticeable adhesion was seen in the control group.
The histomorphometric results of this study are presented in Table 1. PRP treated tendons showed superior healing process than the controls. Furthermore, the matrix appeared more organized and aligned with the extended axis of the tendon (fibrillar linearity) (P = 0.027). In addition, PRP treated group revealed a higher rate of fibrillar continuity at the repaired site in comparison with the control group (P = 0.0005) (Fig. 2A vs. 2B). However, the control specimens exhibited remarkable disorganized matrix showing disruption of the normal linear direction of collagen bundles and characterized by displaying fibril in an irregular pattern in comparison with the treatment group. The gradual increase in cellularity was seen in PRP treated group. The orientations of nuclei indicated that, in these areas, the cells in PRP group were arranged in line with the long axis of the tendon and that was not seen in the control group (Fig. 2C vs.2D). PRP treated group showed greater neovascularization of neotendon than the control group, however, this difference did not reach statistical significance (P = 0.066). Epitenon thickness and its neovascularization were also significantly increased in treatment group (P = 0.013 and P = 0.002), respectively. Finally, more collagen deposition was observed in the PRP treated group in comparison with the control group according to the Masson's trichrome stain tendons sections. The significant difference in collagen deposition was demonstrated in Fig. 3A, B.
PRP treated group showed an increase in force at failure (P = 0.005) and energy absorption (P = 0.031) as compared to controls. PRP treated group showed greater stiffness than the control group, however, this difference did not reach statistical significance (P = 0.055).
Figure 1. The box plot shows the change in platelet count in the process of PRP preparation
Figure 2. Photomicrographs demonstrating the differences in the histological appearances between the groups. Parallel orientation of collagen fibers in treatments indicating superior remodeling of neotendon (A) compared to controls (B). There was increased cellularity which changes in cell morphology. Arrows show the cells, in PRP group arranged in line with the long axis of the tendon, well oriented collagen clearly was seen. (C) Such a well-organized structure was not seen in control group (D) (H&E, 100×).
Circulation-derived mediators such as growth factors have a key role in the healing processes of tissues. 6 In the initial stage of tendon healing process, growth factors are temporarily elevated in the injured area to initiate the healing process and decrease in number with time. Reportedly, a delay of time-dependent decrease in blood derived products, could improve tendon healing. 7,8 Therefore, PRP therapy provides possibility of access to an autologous source of growth factors to optimize tendon healing. PRP contains a higher concentration of platelet levels in the whole blood. About 4-5 times more than the baseline concentration was enough to improve tissue healing. 10, 11, 19 A platelet concentration of obtained PRP in this study was about 4.08 times higher than the baseline concentration when compared to the whole blood. Not all PRP were the same. PRP that has not been activated may be the appropriate form. Activation of PRP by the thrombin and or calcium before application, however, results in the rapid discharge of growth factors, which may not be ideal. The collagen within musculoskeletal tissues like tendons may activate the platelet slowly, resulting in a sustained release of growth factors.19,20 Therefore, in this study we used the non-activated form of PRP. The results of the present study showed that the injection of PRP to the site of tendon rupture could improve structural and histological properties of rabbits DDF tendon. This effect was probably due to the growth factors that are released from the platelet. Mature tendons were poorly vascularized.21 Kakar et al. reported that the early stages of healing were characterized by a marked increase in vascularity, in which neovascularization provides the delivery of the inflammatory mediators to the wound site.22 Wounding promotes the release of the growth factors and cytokines from platelet, macrophages, and other inflammatory mediators. These growth factors prompt the chemotaxis and neovascularization of the fibroblasts and tenocytes. The injection of PRP into the mouse leg ischemia model intensifies the angiogenesis and blood reperfusion of ischemic tissues in comparison with the control group.23 The neovascularization was greater in the PRP treated group in comparison with the control group, however, this increase was not significant between the groups. The angiogenic effect of PRP is ascribed to the presence of vascular endothelial growth factor and fibroblast growth factor which are crucial for stimulating angiogenesis to bring nutrients and progenitor cells to the injury site.24, 25 Both intrinsic and extrinsic mechanisms are likely to play a key role in the healing process in tendon.
Figure 3. Representative figures for mature collagen synthesis from control group (A) and PRP group (B). Masson’s Trichrom stain. Original Magnification x100. Blue staining resembles mature collagen. (B) demonstrates a generally well-structured tendon. (A) shows weaker blue staining than (B) indicating less collagen deposition.
Treatment 3 W.
Fibrillar Linearity (%)
No. Of Capillaries In Neotendon
No. Of Capillaries In Epitenon
abValues with different symbol in each column are significantly different (p<0.05).
Table 1. Results of hostomorhometric analysis (mean ±SD) of repairs three weeks after surgery.
The intrinsic mechanism involves proliferation of tenocytes from the epitenon and endotenon. These tenocytes help to synthetize the new extracellular matrix. Such innate healing causes less restrictive formation of the adhesions and enhances the biomechanics of neotendon. On the other hand, the extrinsic mechanism includes the movement of inflammatory cells and fibroblasts from the sheath and synovium into the lesion site to engender scar tissue and causes less satisfactory biomechanics and adhesion formation which prevents tendon gliding. Neovascularization and proliferation of fibroblasts in the synovial layer of epitenon and wound site lead to an increase in the epitenon thickness and accelerate the healing of tendon. That is one mechanism which improves the intrinsic healing activity of the tendon.26, 27 In this study, in addition to the increased neovascularization in neotendon, the higher rate of angiogenesis within epitenon and also the increase of epitenon thickness was seen in the PRP treated group, which could suggest the positive effects of PRP in the improvement of the intrinsic healing capacity of ruptured tendon. During tendon repair, the defect site isreplaced with new tendinous tissue, composed mainly of collagen fibers. This form of neotendon consists of randomly oriented and less organized collagen fibers. With time, collagen fibers are organized in parallel arrays along the line of stress, which take around six weeks, in normal conditions.26,28 whereas in the present study PRP injection accelerated the occurrence of this event in the treatment group compared to the control group, as was demonstrated by the significant increase in fibrillar linearity. The goal of tendon repair is the tendon continuity and function, as well as, the intrinsic mechanism which is responsible for the reorganization of the collagen fibers and the maintenance of fibrillar continuity.29 In the present study, PRP application clearly resulted in an increase in fibrillar continuity in the treatment group. Reportedly, platelet-derived growth factor (PDGF) and transforming growth factor (TGF) increase collagen production by tendons.30 Thus, these growth factors in PRP could increase the synthesis of collagen fibers as was found by more collagen deposition in the Masson’s Trichrome staining in PRP treated group in comparison with the control group in this study.31 The goal of tendon healing is to produce an anastomosis of great tensile strength.32 Studies have shown that the epitenon is the most proliferative structure in the tendon repair process and plays a crucial role in the healing process via extracellular matrix production, including type I collagen in the repair site.26,27 PRP promotes proliferation and activity of epitenon cells that lead to improved collagen synthesis and fiber orientation, results in increased tendon mechanical properties33, which we found in the present study. Application of PRP in rats Achilles tendons improved not only collagen production in healed tendons, but also their tensile strength. 34 Hence, the re-rupture of a repaired tendon which commonly occurs early in the repair process as a rapid increase in mechanical strength is important clinically.34,36 The present study demonstrated a significant increase in force at failure and energy absorption of PRP treated tendons. These data were in agreement with the results of other studies. 35, 37, 38 The increased tensile strength could result from the improvement in production and remodeling of collagen fibers in the treatment group.26,39 In the present study collagen synthesis increased, however, the major limitation of this study was the lack of collagen type expression data to support our biomechanical results. A stronger tendon exhibits a higher energy storing to eliminate any damages. If this capacity is not enough, the needs in energy absorption and release may rapidly exceed the tendon capacity and may cause an increased danger of lesion. Accordingly, one of the main points in the treatment of tendon lesions is intensifying the energy absorption capacity of the repaired tendon.2,40,41 This study showed that PRP therapy caused a significant increase in the energy absorption capacity in the treatment group in comparison with the control group. The present study did not demonstrate any difference in the tendon stiffness among the groups. Collagen cross-links is a key factor in tendon stiffness. An increase in collagen cross-linking causes an increase in tendon stiffness. Reportedly, the maturation stage of tendon repair occurs after approximately 10 weeks, which includes an increase in collagen fiber crosslinking and the formation of more mature and stiffer tendon.41-43 Accordingly, in the present study, collagen fibers in repaired tendons did not reach the time for appropriate cross-linking at the time of sampling. This result is in line with the other studies 44. The better structural and mechanical parameters at three weeks in the treatment group suggested that PRP improved the rate of intrinsic mechanism of tendon healing. On the other hand, intratendinous injection of PRP caused the acceleration of early tendon healing process in the DDF tendon rupture. The results of this study showed that PRP was a simple, safe, quick and cost effective way to obtain a natural concentration of autologous growth factors which decreased the risk of rupture after the primary tenorrhaphy and enhance functional outcomes.
This study is for DVM thesis at Tabriz Veterinary Medicine Faculty. Authors would like to acknowledge University of Tabriz for financial support of this study.
